Pilot USA ProMax Passive (PNR) Aviation Headset

The ProMax Passive (PNR) from Pilot USA brings premium passive noise reduction, dual-device connectivity, and modular connector flexibility—all in one lightweight, high-value headset.

Key Features & Benefits

• 24 dB Passive Noise Reduction (PNR) for cockpit noise attenuation without electronics or active circuitry
• Dual-device connectivity: use two audio sources simultaneously (e.g. intercom + tablet)
• Record-out to camera, digital recorder, or smartphone via AUX / record out jack
• USB-C external power input for optional power boost
• Detachable communication cords allow connector variants: GA dual plugs, Helicopter plug, or 6-pin LEMO panel power
• Mono / Stereo switch, dual volume controls, auto shut-off to conserve battery
• Three-year manufacturer warranty included

Detailed Description

The ProMax Passive (PNR) headset from Pilot USA is engineered for pilots seeking a reliable, no-electronics, passive solution with modern flexibility. At approximately 14.9 oz (422 g), it ranks among the lightest headsets in its class while delivering robust noise attenuation and connectivity features.

Its modular wiring system supports three connector styles: standard GA dual plugs, a single helicopter plug, or a 6-pin LEMO for panel power installations. Users can change cords as needed. The headset supports simultaneous use of two audio sources (e.g. intercom and tablet), and features a record-out jack to capture radio audio on cameras or recorders. A USB-C port allows external power to extend performance beyond AA battery life.

Comfort and usability are top priorities: the ProMax Passive includes protein-leather ear seals, a soft head pad, adjustable memory-flex boom mic, and dual volume controls. Its auto shut-off feature helps conserve battery life when inactive. With a 3-year warranty, it’s built for dependable performance.

Connector / Variation Options

When ordering, you can select the preferred connector variant. Each shares the same core headset features, but differ in interface compatibility:

• GA Dual Plugs – standard .25″ audio + .206″ mic plugs, suitable for most fixed-wing general aviation aircraft
• Helicopter Plug – single plug commonly used in many rotorcraft
• 6-Pin LEMO (Panel Power) – ideal for aircraft with panel-powered headset jacks

Technical Specifications

Specification	Value
Noise Reduction Rating (PNR)	24 dB (passive)
Microphone Type	Noise-canceling electret (amplified)
Speaker Impedance	300 Ω
Weight	14.9 oz / 422 g
Connector Options	GA Dual Plugs / Helicopter / 6-Pin LEMO
Batteries	2 × AA (20–25 hours typical)
Warranty	3 years (Pilot USA)
